Features:

NEW elegant design / 7''Luxury HD color LCD Screen / Intercom,monitor,unlock functions / Suitable for single house, office and villa,etc /One camera can work with four monitors max.

Specifications:
LCD: 7" TFT-LCD
Voltage Input: 100V AC~ 250V AC
Voltage Output: +12V DC
Pixel: 105,600 dots
Current Output: 1.2A
Standby Current: ≤25mA
Working Current:  ≤600mA
Video System: PAL/NTSC
Power Output:  ≥50mV
Working Humidity: 45%~95%
Working Tempareture: -30℃~+55℃
Installation: Surface mount
External Dimension:  250x160x28 mm

OUTDOOR UNIT

Features:
Mini style outdoor unit / Pinhole camera with weather-proof & Vandal-proof design / Pure metal casing / Infrared LED light compensation / One camera can work with four monitors max.

Specifications:
Power input: +12VDC ( supplied by indoor unit)
H. Resolution: 420TV Lines
Image sensor: 1/3" SONY SHAD CCD
Min illumination: 0.8 LUX @ F1.2
Video System:  PAL /NTSC
S/N Rate:  >48dB
Standby Current:  Working Current:  Working Temperature: -30℃-55℃ (-22-131 )
Working humidity:  45% - 85%
Installation: surface mount
Wiring: 4-wire
External Dimension: 122×58×28mm
